Crosby G-291 3/4X15 Inch Forged Regular Eye Bolt With Nut Galvanized 1043677

Name: Crosby G-291 3/4X15 Inch Forged Regular Eye Bolt With Nut Galvanized 1043677
Brand: Crosby
SKU: 38-01084
Availability: InStock

SB#38-01084

Discontinued

Forged Steel Quenched & Tempered Regular Eye Bolt. Recommended For In-Line Pull. Fatigue Rated At 1-1/2 Times The WLL at 20000 Cycles. Meets Or Exceeds All Requirements Of ASME B30.26

Working Load Limit 7200 Lbs
Ultimate Load is 5 times the Working Load Limit.
Maximum Proof Load is 2 times the Working Load Limit
All bolts are hot dip galvanized after threading (UNC). Comes with hot dip galvanized heavy hex nut.
These meet other critical performance requirements including fatigue life, impact properties and material traceability not addressed by ASME B30.51

MIN QTY: 1

1043677

G-291
