Crosby G-209A 1 1/4 Forged Alloy Screw Pin Anchor Shackle 18 Ton WLL Galvanized 1017626
Specifications

Body Material Forged Alloy Steel
Eye Outer Size 3 in
Finish Hot Dipped Galvanized
Inner Length 4.69 in
Inner Width 3-1/4 in
Load Capacity 18 ton
Opening Size 2.03 in
Overall Length 8-1/4 in
Overall Width 6.16 in
Pin Diameter 1.38 in
Pin Material Alloy Steel
Pin Type Screw
Series G-209A
Size 1-1/4 in

Crosby G-209A 1 1/4 Forged Alloy Screw Pin Anchor Shackle 18 Ton WLL Galvanized 1017626

SB#48-01326
Special Order-Shipping Times Vary
Crosby G-209A 1 1/4 Forged Alloy Screw Pin Anchor Shackle 18 Ton WLL Galvanized 1017626

WEB PRICE:

$292.28/EA/EA

G-209A Screw pin anchor shackles meet the performance requirements of Federal Specification RR-C271F Type IVA, Grade B, Class 2, except for those provisions required of the contractor

  • Working Load Limit Meets performance requirements of Grade 8 shackles. Permanently Shown On Every Shackle
  • Forged Alloy Steel - Quenched And Tempered, With Alloy Pins.
  • Meets Or Exceeds All Requirements of ASME B30.26
  • Importantly, these shackles meet other critical performance requirements including impact properties and material traceability, not addressed by ASME B30.26.
  • Working Load Limit: 18 Ton
MIN QTY: 1

1017626
G-209A
Crosby
