Specifications
Body Material Carbon Steel
Eye Outer Size 3 in
Finish Hot Dipped Galvanized
Inner Length 4.69 in
Inner Width 3-1/4 in
Load Capacity 12 ton
Opening Size 2.03 in
Overall Length 8-1/4 in
Overall Width 6.69 in
Pin Diameter 1.4 in
Pin Material Alloy
Pin Type Bolt
Series G-2130
Size 1-1/4 in
Crosby G-2130 1 1/4 Forged Bolt Type Anchor Shackle 12 Ton WLL Galvanized 1019597
SB#48-01310
Special Order-Shipping Times Vary
WEB PRICE:
$317.93/EA/EA
Bolt Type Anchor Shackles With Thin Head Bolt And Nut With Cotter Pin. Meets The Performance Requirements Of Federal Specification RR-C271F Type IVA, Grade A, Class 3, Except For Those Provisions Required Of The Contractor.
MIN QTY: 1
Crosby
1019597
G-2130
Catalog
