Specifications
Chamfer Type Plug
Class of Fit 6H
Cutting Direction Right Hand
Finish/Coating Steam Oxide
Material HSS-E
Material Application Steel, Stainless Steel and Cast Iron
Measurement System Metric
Number of Flutes 3
Overall Length 95 mm
Series E011
Shank Diameter 11.2 mm
Thread Length 24 mm
Thread Limit D7
Thread Size M14x1.5
Thread Standard UNF
Dormer E011 14mm – 1.5 3 Flute Spiral Point Machine Tap 5974427
SB#20-07334
Ready To Ship
WEB PRICE:
$88.45/EA/EA
Spiral point tap with chamfer form B with a 3.5-5xP plug lead, for ISO-Metric Fine thread M12 with 1.00 mm pitch and 6H class of fit, dimensions according to ISO 529 standard with 9.0mm shank and 7.1mm square drive, powder metallurgical HSS-E with steam tempered surface finish for 2.5xD through hole threading in general purpose applications
MIN QTY: 1
Dormer Pramet
5974427
E011
