Enerpac RLT-110 12.5 Ton Hydraulic Cylinder Single Acting Low Height Multi Stage Telescopic 0.71 Inch Stroke 398911

Specifications

Maximum Operating Pressure (psi) 10150

Capacity Class (tonnage) 12

Maximum Cylinder Capacity Advance (short tons) 12.5

Stroke (in) 0.71

Collapsed Height A (in) 2.15

Extended Height B (in) 2.85

Return Type Single-Acting, Load Return

Plunger Type Telescopic

Material Steel

Oil Capacity Advance (in3) 2.9

Stage 1 Capacity Ton 26.1

Stage 1 Stroke S1 in 0.43

Stage 2 Capacity Ton 12.5

Stage 2 Stroke S2 in 0.28

Surface Treatment Nitride

Coupler CR400

Enerpac RLT-110 12.5 Ton Hydraulic Cylinder Single Acting Low Height Multi Stage Telescopic 0.71 Inch Stroke 398911

Name: Enerpac RLT-110 12.5 Ton Hydraulic Cylinder Single Acting Low Height Multi Stage Telescopic 0.71 Inch Stroke 398911
Brand: Enerpac
SKU: 284-00580
Availability: InStock

SB#284-00580

Special Order-Shipping Times Vary

WEB PRICE:

$1,914.22/EA/EA

Single-Acting, Load Return Cylinder For Use In Confined Spaces: Machinery Positioning, Tool Fastening. The Longer Stroke Length Of Telescopic Cylinders Will Save You Time And Simplify Projects By Moving A Load A Greater Distance And Eliminating The Use Of Temporary Cribbing.

Nitrocarburization surface treatment for improved load and wear resistance and corrosion protection
Mounting bolt holes for easy fixturing
Design safety factor complies with ASME B30.1 & EN1494
Up to 3% side-load of maximum capacity
High-Alloy steel for maximum strength

MIN QTY: 1

Enerpac

398911

Technical Data Sheet
